436 Keysight EXG and MXG X-Series Signal Generators User’s Guide
Using the N5102A Digital Signal Interface Module for N5172B/82B with Option 003/004 and
653/655/656/657
Operating the N5102A Module in Output Mode
From this menu, choose a logic type.
2. Select the logic type required for the device being tested.
A caution message is displayed whenever a change is made to the logic types, and a softkey
selection appears requesting confirmation.
3. Refer to Figure 17-11. Press the Port Config softkey.
In this menu, select either a serial, parallel, or parallel interleaved data transmission.
4. Select the port configuration for the device.
Selecting the Output Direction
Press Data Setup > Direction Input Output to Output and press Return.
Selecting the Data Parameters
This procedure guides you through the data setup menu. Softkeys that have self-explanatory
names are generally not mentioned. For example, the Word Size softkey.
1. Refer to Figure 17-12. Press the Data Setup softkey.
Changing the logic type can increase or decrease the signal voltage level
going to the device under test. To avoid damaging the device and/or the
N5102A module, ensure that both are capable of handling the voltage
change.
Within the data and clock setup softkey menus, some softkeys function
relative to the current configuration. Softkeys that are grayed out are not
available for the current setup.
If Option 003 is the only option installed, the direction softkey will be
unavailable and the mode will always be output. With both Option 003
(output mode) and Option 004 (input mode) installed, the default direction
is output.
