For details on each key, use key help as described on page56.
Mode > Dual ARB > More >
Waveform Licensing > Add
Waveform to First Available Slot
or
Mode > Dual ARB > More >
Waveform Licensing > Replace
Waveform in Slot
The softkey is greyed out, if a
waveform is already licensed or does
not require licensing.
This softkey displays a catalog
of the waveform segments
stored in the Int Storage or
USB Media.
This softkey displays a catalog
of the waveforms stored in the
BBG memory.
To select a waveform, use
the arrow keys to highlight
the waveform and then
press Add Waveform.
Note: Waveforms licensed with Option 2xx cannot be “exchanged”. Once a slot is locked,
that license for the waveform in the locked slot is permanent and cannot be revoked or
replaced.
Refer to the SCPI Command
Reference for related License
Commands.
The waveform to be added or replaced can be selected from BBG memory, internal storage, or a USB device.
