162 Keysight B2980B User’s Guide, Edition 1
Front Panel Reference
Display and Assist/Function Keys
The file can be saved onto a USB flash drive connected to the
front panel USB-A connector. The file is saved with the
specified name. If the file extension is not specified, “.jpg” is
added automatically.
Show Cursors Displays the cursors (Y-cursors 1 and 2, X-cursors 1 and 2, and
cursor data) and changes the softkey label to Hide Cursors.
Hide Cursors Hides the cursors and changes the softkey label to Show
Cursors.
Show Ref. Displays the reference line using the saved measurement data
as the reference line data, and changes the softkey label to
Hide Ref..
Hide Ref. Hides the reference line, changes the softkey label to Show
Ref..
Save as Ref. Saves the presently-displayed data as the reference line data
temporarily.
Show Source Displays the output voltage value of the voltage source and
changes the softkey label to Hide Source.
Hide Source Hides the output value of the voltage source and changes the
softkey label to Show Source.
If the number of data exceeds 5000
If the number of measurement data exceeds 5000, the Graph view and the Roll
view plot the following data. Where, n is integer, 1 to 5000.
Number of data is 5001 to 10000: [2*(n1)1]th data
Number of data is 10001 to 25000: [5*(n1)1]th data
Number of data is 25001 to 50000: [10*(n1)1]th data
Number of data is 50001 to 100000: [20*(n1)1]th data
