Function Details
Measurement Time
Figure 5-2 Voltage Source Output and Measurement Timing, Sweep Output Example
To set the delay time and the period, see “Trigger Setup Sub-panel” on page 157.
For more information about the trigger setup, see “Trigger Key Group” on
page 182.
Voltage or current
Start value
Previous value
Trigger
: Measurement
Time
Stop value
Trigger
Trigger
Source delay (1)
Period (3)
(2)
(2)
(1) (1)
(3)
Measure delay (2)
