Keysight B2980B User’s Guide, Edition 1 39
Introduction
Front View
Table 1-5 Display Setup
Table 1-6 File Operations
Task Relevant front panel key
To change the color set System Menu > Display > Color Set function keys
To perform zoom-in/out Meter view Zoom function key
System Menu > Display > Zoom function keys
To change the data digits System Menu > Display > Digits function keys
To enable or disable the display when the instrument
is in the remote condition
System Menu > Display > Remote function keys
To show or hide Histogram preview Show Hist. or Hide Hist. assist key
To show or hide Roll preview Show Roll or Hide Roll assist key
To show or hide the display of secondary
measurement data, temperature data, and/or
humidity data, for B2985B/B2987B
System Menu > Display > Pref. function keys
Task Relevant front panel key
To save a measurement result data to a USB flash
drive
System Menu > File > Save > Measure function keys
To save a math result data to a USB flash drive System Menu > File > Save > Math function keys
To save a limit test result data to a USB flash drive System Menu > File > Save > Limit Test function keys
To save a trace buffer data to a USB flash drive System Menu > File > Save > Trace function keys
To save a system setting data to a USB flash drive System Menu > File > Save > Config function keys
To save a graph screen damp to a USB flash drive Dump Screen assist key on Graph/Roll/Histogram view
To load a system setting data from a USB flash drive System Menu > File > Load > Config function keys
To load a license file from a USB flash drive System Menu > File > Load > License function keys
To load a list sweep data from a USB flash drive Load assist key for the list sweep Start/Stop/Points field in
the EDIT status
