TOS3200
Setting the TC Measurement and PCC Measurement
Setting the Measurement Range
TC:RANG:SEL / PCC:RANG:SEL
Sets the measurement range (RANGE).
Command [SENSe:]TC:RANGe:SELect {AUTO|FIXed}
[SENSe:]TC:RANGe:SELect?
[SENSe:]PCC:RANGe:SELect {AUTO|FIXed}
[SENSe:]CC:RANGe:SELect?
Parameter Value: AUTO Auto range switching (default)
p. 55, p. 59
FIX Fixed range
For TC measurement, the range is determined by the upper refer-
ence, measurement network, and current measurement mode set-
tings.
For PCC measurement, the range is determined by the upper refer-
ence and current measurement mode settings.
Response Returns the measurement range in the <character> form.
Querying the Settings
TC / PCC
Queries the settings.
Command [SOURce:]TC?
[SOURce:]PCC?
Response
Returns the following settings in order in the <string> form in response TC? / PCC?:
measurement mode, measurement network, measurement range, connection destination,
polarity, single fault mode, lower reference, lower reference on/off, upper reference, upper
reference on/off, test time, test time on/off, test wait time, test wait time on/off.
NA is always returned for the measurement network and connection destination in response
to PCC?. NA may be returned for the polarity and single fault mode.
NA may be returned for the polarity and single fault mode depending on the connection set-
ting in response to TC?.
(Example) When the settings are as follows: measurement mode: RMS, measurement net-
work: A, measurement range: FIX, connection destination: ENCPE, polarity: REV,
single fault mode: FLTNEU, lower reference: 30 μA, lower reference on/off: on,
upper reference: 30 mA, upper reference on/off: on, test time: 1 s, test time on/off:
on, test wait time: 1 s, and test wait time on/off: on
In response to TC?
Returns “RMS,A,FIX,ENCPE,REV,FLTNEU,+3.00000E-05,
1,+3.00000E-02,1,+1.00000E+01,1,+1.00000E+01,1”.
In response to PCC?
Returns “RMS,NA,FIX,NA,REV,FLTNEU,+3.00000E-05,
1,+3.00000E-02,1,+1.00000E+01,1,+1.00000E+01,1”.
