Kikusui TOS3200 - Setting Test Conditions of the PCC Measurement

56 TOS3200
Setting Test Conditions of the PCC Measurement
Press the MANUAL key to display the PCC measurement screen 1/2 (PCC1/2).
The PCC measurement screen consists of two screens, PCC1/2 and 2/2.
p. 32
For the procedure to select items and enter data, see “Screen Configuration”.
p. 42
For the procedure to connect the EUT, see “Connecting the EUT”.
Setup Items of PCC1/2 (POL / COND)
SYSTEM
MANUAL
I / FEDIT
AUTO
See
See
PCC 1 / 2
READY
OFF ON
LOWER
UPPER TIMER
NORM
POL
NORM
COND
UPPER
OFF
TIMER
30.0 mA 10 s
LOWER UPPER TIME/WAIT
Item Description Panel operation
Selects the polarity of the power line supplied to the EUT.
POL NOR/RVS
(SHIFT+F1) key
NORM Positive phase connection
REVS Negative phase connection
Selects the single fault mode.
CONDITION
(SHIFT+F2) key
NORM Normal status
FLT
NEU Power line (neutral) disconnected status
POL
COND
