170
TOS3200
Specifications
Judgment Function
Pass/fail judgment Judgment with respect to the upper and lower current reference
Judgment method Window comparator
Judgment action Judgment starts after the test wait time elapses.
The buzzer volume can be set in the range of 0 (off) to 10 sepa-
rately for PASS and FAIL.
The buzzer is valid only for the total judgment result during a pro-
gram test.
UPPER
FAIL
Judgment method Indicates U-FAIL judgment if a current greater than or equal to the
upper reference is detected.
Indication Shows U-FAIL on the display.
Buzzer On
SIGNAL I/O Outputs a U-FAIL signal.
LOWER
FAIL
Judgment method Indicates L-FAIL judgment after the timer value elapses if a cur-
rent less than or equal to the lower reference is detected.
Indication Shows L-FAIL on the display.
Buzzer On
SIGNAL I/O Outputs an L-FAIL signal.
PASS Judgment method Indicates PASS judgment after the timer value elapses if the test
is not a failure.
Indication Shows PASS on the display.
Buzzer On
SIGNAL I/O Outputs a PASS signal.
PASS HOLD The time to hold the PASS judgment can be set to a value
between 0.2 s and 10.0 s or HOLD (buzzer is fixed to 0.2 s).
Selectable range
of LOWER/
UPPER
RANGE1 PCC DC, RMS: 30 μA to 600 μA, PEAK: 50 μA to 850 μA
Network A, B, B1,and C
Network D and E DC, RMS: 30 μA to 300 μA, PEAK: 50 μA to 424 μA
Network F DC, RMS: 30 μA to 200 μA, PEAK: 50 μA to 282 μA
Network G DC, RMS: 30 μA to 150 μA, PEAK: 50 μA to 212 μA
RANGE2 PCC DC, RMS: 601 μA to 6.00 mA, PEAK: 851 μA to 8.50 mA
Network A, B, B1,and C
Network D and E DC, RMS: 301 μA to 3.00 mA, PEAK: 425 μA to 4.24 mA
Network F DC, RMS: 201 μA to 2.00 mA, PEAK: 283 μA to 2.82 mA
Network G DC, RMS: 151 μA to 1.50 mA, PEAK: 213 μA to 2.12 mA
RANGE3 PCC DC, RMS: 6.01 mA to 30.0 mA, PEAK: 8.51 mA to 90.0 mA
Network A, B, B1,and C
Network D and E DC, RMS: 3.01 mA to 30.0 mA, PEAK: 4.25 mA to 45.0 mA
Network F DC, RMS: 2.01 mA to 20.0 mA, PEAK: 2.83 mA to 30.0 mA
Network G DC, RMS: 1.51 mA to 15.0 mA, PEAK: 2.13 mA to 22.5 mA
Judgment accuracy Conforms to the measurement accuracy.
Read rdng as UPPER setting in the measurement accuracy.
