SIGNAL I/O Connector
The SIGNAL I/O connector is the D-sub 25-pin connector on the rear panel.
The connector is used to control the starting and stopping of the test or monitor the TOS3200
status.
• Connector on the TOS3200
By Omron XM2B-2502 D-sub 25-pin male connector
• Connection cable
D-sub 25-pin male to D-sub 25-pin male, straight cable
• Connector on the controller
By Omron XM2D-2501 D-sub 25-pin male connector or an equivalent connector
To prevent operation errors due to noise, use a shielded D-sub 25-pin connector and a cable
of length less than or equal to 3 m.
For information on how to obtain the consumable parts, contact your Kikusui agent or distrib-
utor.
For details on how to use the tools, read the catalog by Omron.
SIGNAL I/O Specifications
Input signal
Low-active control input
High-level input voltage: 11 V to 15 V
Low-level input voltage: 0 V to 4 V
Low-level input current: -5 mA maximum
Input time width: 5 ms minimum
Output signal
Open collector output
Output withstand voltage: 30 Vdc
Output saturation voltage: Approx. 1.1 V (25 °C)
Maximum output current: 400 mA (TOTAL)
WARNING
Possible electric shock. Turn off all equipment before connecting or disconnecting
cables.
