SCPI Register Model
OPERation Status Register
The OPERation status register is a 16-bit register which contains information about condi-
tions which are part of the TOS3200 normal operation.
STAT:OPER
Queries the event of the OPERation status register.
A query clears the contents of the register.
Command STATus:OPERation[:EVENt]?
Response
Returns the event of the OPERation status register in the <NR1> form.
STAT:OPER:COND
Queries the condition of the OPERation status register.
A query does not clear the contents of the register.
Command STATus:OPERation:CONDtion?
Response
Returns the condition of the OPERation status register in the <NR1> form.
Bit
Decimal
value
Bit name Description
0 1 Terminal [A] is active Terminal A is active.
1 2 Terminal [B] is active Terminal B is active.
2 4 EUT LINE is active The power line of the EUT is active.
38
DANGer (AB voltage is
exceeding SELV voltage)
The voltage between terminals A and
B exceeds the SELV voltage while the
test is in progress.
4 16 NOT USED –
5 32 Waiting for TRIGger The TOS3200 is waiting for a trigger.
6 64 Test is under HOLD state Hold state
7 128 NOT USED –
8 256 Test PASSed Pass judgment
9 512 Test FAILed Fail judgment
10 1024 TEST running Test in progress
11 2048 STOP key is being pressed The STOP switch is pressed.
12 4096 Test is under WAIT state Test wait time status
13 8192 Test is under INTerval state Interval state
14 16384 Auto PROGram test running Program test is in progress.
15 32768 NOT USED –
