Setting Test Conditions of the PCC Measurement
Setup Items of PCC1/2 (LOWER / UPPER / TIMER / WAIT)
p. 50
For a description of the LOWER, UPPER, and TIME/WAIT settings, see also “Judgment Sys-
tem”.
Table 4-5 Selectable range of LOWER/UPPER
See
PCC 1 / 2
READY
OFF ON
LOWER
UPPER TIMER
NORM
POL
NORM
COND
UPPER
OFF
TIMER
30.0
mA
10
s
LOWER UPPER TIME/WAIT
Item Description Panel operation
Sets the lower limit of the judgment reference.
If LOWER ON is specified and a current less than or equal to the lower ref-
erence is measured, L-FAIL judgment will result.
LOWER (F3) key
Lower
reference
The selectable range varies depending on the MODE (current
measurement mode) setting on PCC2/2. See Table 4-5.
Rotary knob
OFF Disables the lower reference judgment.
LOWER ON/OFF
(SHIFT+F3) key
ON Enables the lower reference judgment.
Sets the upper limit of the judgment reference.
If UPPER ON is specified and a current greater than or equal to the upper
reference is measured, U-FAIL judgment will result.
UPPER (F4) key
Upper
reference
The selectable range varies depending on the MODE (current
measurement mode) setting on PCC2/2. See Table 4-5.
Rotary knob
OFF Disables the upper reference judgment.
UPPER ON/OFF
(SHIFT+F4) key
ON Enables the upper reference judgment.
Sets the test time (TIMER) or the test wait time (WAIT).
If TIMER is selected, you can set the test time and TIMER ON/OFF. If WAIT
is selected, you can set the test wait time and WAIT ON/OFF.
TIME/WAIT (F5)
key
Test time
Set the test time in the range of 1 s to 999 s.
The test time will start when the test wait time elapses.
Rotary knob
TIMER OFF
The specified test time is ignored.
Press the STOP switch to stop the test.
TIMER ON/OFF
(SHIFT+F5) key
TIMER ON The test will stop when the specified time elapses.
Tes t w a i t
time
Set the time until the test is actually started after the START
switch is pressed (test wait time) in the range of 1 s to 999 s.
Rotary knob
WAIT OFF The specified test wait time is ignored.
WAIT ON/OFF
(SHIFT+F5) key
WAIT ON The actual test will start when the specified test wait time elapses.
MODE Selectable range
DC, RMS 30 μA to 30.0 mA
PEAK 50 μA to 90.0 mA
