Kikusui TOS3200 - Measuring in Meter Mode

72 TOS3200
Measuring in Meter Mode
In Meter Mode, the TOS3200 measures and displays the current flowing through measure-
ment terminals A and B or the voltage between A and B as with a general multimeter. The
TOS3200 does not judge the results against the reference.
Press the MANUAL key to display the meter mode measurement screen 1/2 (METER1/2).
The meter mode measurement screen consists of two screens (METER1/2 and 2/2). There
are no items that you set on METER1/2. The displayed value is the present measured value.
p. 70
For the procedure to connect the EUT, see “Connecting the EUT”.
Displaying the voltage between the measurement network refer-
ence points
p. 176
Press the V DISP (SHIFT+F5) key while the measured current is displayed to display the volt-
age between the measurement network reference points.
Maximum Value Hold Function of the Measured Current
(MEAS MODE)
This function holds and displays the maximum value measured.
The held maximum value is cleared when you press the MAXCLR (F4) key.
1
Select the MEAS MODE on SYSTEM1/5.
2
Use the rotary knob to select the NORM or MAX.
SYSTEM
MANUAL
I / FEDIT
AUTO
See
METER1 / 2
0 µA
NTWK A
CURR/VOLT MAXCLR
rms
Indicates the selected
measurement network.
Displayed when the
current is displayed.
Current or voltage
between measurement
terminals A and B
Switches between current measurement
and voltage measurement.
Clears the maximum measured value that is held.
Displayed when MEAS MODE is set to MAX in
SYSTEM1/5.
Current measurement
mode (RMS/DC/PEAK)
See
METER1 / 2
0 µA
0 µA
NTWK A
CURR/VOLT
rms
0.007v
METER1 / 2
NTWK A
CURR/VOLT
rms
Voltage between the measurement
network reference points
F5
Press SHIFT+F5.
SHIFT
NORM Normal measurement (not hold the maximum value)
MAX Hold the maximum value.
