92
TOS3200
Stopping the Test
Program Test Judgment (Cont’d)
Judgment for each step
p. 50
Judgment is performed in the same manner as the single test. For details, see “Judgment
System”.”
The judgment result of each step is displayed on the screen during the interval and also deliv-
ered as a signal from the SIGNAL I/O connector. The buzzer does not sound.
Total judgment
When the program test is complete, a total judgment of all steps is displayed. If the judgment
of all steps is the same, the total judgment is also the same. If various judgments are mixed,
the judgment with the highest precedence becomes the total judgment. See the following
example.
ABORT setting and FAIL judgment
If ABORT is set to OFF in the example of program 01 above, the test will be executed to step
05, and the total judgment will be U-FAIL.
If ABORT is set to ON, CONTACT FAIL occurs in step 01, and the program test will stop at
this point. The total judgment will be CONTACT FAIL, and the test results up to step 01 can
be stored.
Storing the Test Result
p. 93
The storage function is assigned to a function key while the judgment result is displayed. For
details, see “Storing the Test Results”.”
Releasing the Judgment Result
Press the STOP switch to set the TOS3200 to READY status.
See
Step
Judgment of each step
Order of
prece-
dence
Judgment
Program 00 Program 01 1 U-FAIL
00 PASS PASS 2 L-FAIL
01 PASS CONTACT FAIL 3 CONTACT FAIL
02 PASS U-FAIL 4 PASS
03 PASS PASS
04 PASS L-FAIL
05 PASS PASS
Tot al
judgment
PASS U-FAIL
See
To Next Page
