TOS3200
37
3
Panel Control Basics
Selecting the Operation Mode
Single Tests (TC/PCC/METER)
The TOS3200 has three operation modes. Because each mode is independent, the
TOS3200 can be used in any single operation mode.
A measurement in any of the following modes is called a single test.
• TC Measurement Mode
• PCC Measurement Mode
• Meter Mode (METER)
Each operation mode consists of two screens. Each time you press the MANUAL key, the
screen changes as follows:
• When the first screen (1/2) is selected
• When the second screen (2/2) is selected
Program Tests (AUTO)
p. 75
You can also execute program tests that combine the TC measurement and PCC measure-
ment modes. To select the program test, press the AUTO key. For details, see “Program
Test”.
MANUAL
TC1/2 METER1/2 PCC1/2
The operation mode switches each
time you press MANUAL.
MANUAL
TC1/2 METER1/2 PCC1/2
TC2/2 METER2/2 PCC2/2
Press MANUAL to return to the first screen. The
operation mode switches each time you press
MANUAL.
See
To Next Page
