TOS3200
87
Setting Additional Test Conditions
6
Program Test
1
Select the PASS HOLD on SYSTEM1/5.
2
Use the rotary knob to select the PASS HOLD time.
Measured Current Conversion Display (CONV)
The TOS3200 has a function called CONV that converts the measured current by the ratio
between the preset CONV voltage and the measured value of the line voltage applied to the
EUT AC inlet.
For example, if the line voltage is 100.0 V and you set the preset CONV voltage to 106.0 V,
the TOS3200 displays values equal to 106% of the measured currents.
1
Select the CONV on SYSTEM1/5.
2
Use the rotary knob to set the voltage.
Buzzer Volume (BUZ VOL)
You can set the buzzer volume for PASS or FAIL judgments.
1
Select the BUZ VOL on SYSTEM1/5.
Select the BUZ VOL (PASS) to set the buzzer volume for PASS judgments, or select
the BUZ VOL (FAIL) to set the buzzer volume for FAIL judgments.
2
Use the rotary knob to set the buzzer volume (0 to 10).
You can hear the buzzer volume by pressing the BUZ CHK (SHIFT+F5) key when BUZ
VOL (PASS) or BUZ VOL (FAIL) is selected.
Time Selectable range: 0.2 s to 10.0 s
HOLD Hold until the STOP switch is pressed.
AUTO 1 / 2
01 PCC––––––PNRM•NORM––– 1s NETWORK:A
–––END
PRG
01:TEST-1
TOTAL: 2
PASS
SAVE? Yes No
30
µA
0
s
rms
LINE 0.0W
0.0V 0.00A
The PASS HOLD time setting of the program test is valid only when the program test is com-
plete. The PASS judgment display for each step depends on the interval time setting.
Voltage Selectable range: 80.0 V to 300.0 V
OFF Disable the conversion display.
