TOS3200
91
6
Program Test
Stopping the Test
Aborting the Test
Press the STOP switch.
When the Test Ends
The program test will stop in any of the conditions below.
a. When the execution of all steps has been completed.
b. If U-FAIL, L-FAIL, or CONTACT FAIL occurs (when ABORT is ON).
c. When you press the STOP switch.
When the program test stops, the DANGER lamp will turn off, and the power line to the EUT
will be turned off.
If the test stops in the case of condition a or b above, the total judgment result will be dis-
played on the screen.
Program Test Judgment
In a program test, the measured value is judged for each step, and the result is displayed.
When all steps are completed, the total judgment of all steps is made.
Table 6-3 Operation when the step is completed or the program test is completed
*1 The duration of the buzzer for a PASS judgment is fixed to 0.2 s. It does not depend on the
PASS HOLD time.
START
STOP
AUTO 1 / 2
01 PCC––––––PNRM•NORM––– 1s NETWORK:A
–––END
PRG
01:TEST-1
TOTAL: 2
PASS
SAVE? Yes No
30
µA
0
s
rms
LINE 0.0W
0.0V 0.00A
Operation PASS L-FAIL U-FAIL CONTACT FAIL
Display Displays “PASS” on
the screen.
Displays “↓FAIL” on
the screen.
Displays “↑FAIL” on
the screen.
Displays “↕FAIL” on
the screen.
Buzzer (only when
the program test is
completed)
Sounds for 0.2 s.
1
Sounds until FAIL is cleared.
SIGNAL I/O
connector
Outputs the pass sig-
nal for the time speci-
fied by PASS HOLD.
Outputs the L-FAIL
signal until FAIL is
cleared.
Outputs the U-FAIL
signal until FAIL is
cleared.
Outputs the L-FAIL
and U-FAIL signals
until FAIL is cleared.
To Next Page
