74
TOS3200
Measuring in Meter Mode
NTWK, MODE, and RANGE Settings on METER2/2 (Cont’d)
*3 You cannot select this item if voltage display is specified on METER1/2. The voltage measure-
ment range is as shown in Table 5-2 and is set to AUTO range.
Table 5-1 Measurement range of fixed ranges
Table 5-2 Voltage measurement range
The measured value is blinking
If the measured value exceeds the measurement range specified by AUTO or a range set-
ting, the measured value blinks.
Item Description Panel operation
Selects the electric current measurement mode. MODE (F2) key
RMS RMS measurementMODE (SHIFT+F2) key
MODE
(SHIFT+F2) key
DC DC measurement
PEAK Peak measurement
*2
Selects the measurement range.
RANGE (F3) key
AUTO Automatically switches the range based on the measured value.
RANGE
(SHIFT+F3) key
RANGE1 The measurement range is determined by the measurement net-
work (NTWK) and current measurement mode (MODE) settings.
See Table 5-1 for details.
RANGE2
RANGE3
Measure-
ment range
setting
MODE
Measurement range
NTWK A, B, B1, C NTWK D, E NTWK F NTWK G
Range 1
DC, RMS 30 μA to 600 μA 30 μA to 300 μA 30 μA to 200 μA30 μA to 150 μA
PEAK 50 μA to 850 μA 50 μA to 424 μA 50 μA to 282 μA 50 μA to 212 μA
Range 2
DC, RMS 500 μA to 6.00 mA 250 μA to 3.00 mA 166 μA to 2.00 mA 125 μA to 1.50 mA
PEAK 700 μA to 8.50 mA 350 μA to 4.24 mA 233 μA to 2.82 mA 175 μA to 2.12 mA
Range 3
DC, RMS 5.00 mA to 30.0 mA 2.50 mA to 30.0 mA 1.66 mA to 20.0 mA 1.25 mA to 15.0 mA
PEAK 7.00 mA to 90.0 mA 3.50 mA to 45.0 mA 2.33 mA to 30.0 mA 1.75 mA to 22.5 mA
MODE Measurement range
DC 10.00 V to 300.0 V
RMS 10.00 V to 300.0 V
PEAK 15.00 V to 430.0 V
To Next Page
