MMC Smart Drive Hardware Manual - 230V 1/3 PHASE MMC SMART DRIVE
Figure 5-12: 230V Standard (non -DN) and Narrow (-DN) Drive - Side View
6.12 in
(155.56 mm)
8.79 in
(223.27 mm)
10.13 in
(257.18 mm)
