124 Kollmorgen - December 2011
MMC Smart Drive Hardware Manual - 230V 1/3 PHASE MMC SMART DRIVE
Figure 5-11: 1, 2 and 3 kW Standard Drive (non-DN) - Front View
4.69 in
(119.05 mm)
3.22 in
(81.74 mm)
2.22 in
(56.34 mm)
.50 in
(12.70 mm)
9.69 in
(246.13 mm)
H
E
A
T
S
I
N
K
