MMC Smart Drive Hardware Manual - RESOLVER INTERFACE OPTION MODULE
11.3 Specifications
Characteristics
Resolver Interface Option Module
Specifications
Part Number M.1302.4523
Function Resolver to encoder converter
Field Side Connector F1 Feedback Connector
Excitation Frequency 5 kHz
Output Voltage
4 V
RMS
Current per Output Channel,
max.
28 mA
RMS
Resolver Transformer Ratio 0.5:1.0
Resolver Resolution
4096 Feedback Units (FUs) per electrical rev-
olution
Accuracy Over Temperature
Range
+ 15 minutes
Electrical Velocity, max. 500 RPS
Cable Length, max. 30 M
Power Powered from MMC Smart Drive
