MMC Smart Drive Hardware Manual - INSTALLING THE MMC SMART DRIVE
Figure 3-6: Terminating Power Cables for 460V SDN Drive
A
C
P
W
R
Shield Bracket
Cable Clamp
Cable
Drive
Note: Shield Bracket, Cable
Clamp(s), Cable(s) are
installed by User
