Kollmorgen MMC Smart Drive

Kollmorgen - December 2011 35
MMC Smart Drive Hardware Manual - INSTALLING THE MMC SMART DRIVE
Figure 3-5: Terminating Incoming AC Power (Mains) Cable for 460V SD Drive
Cable Jacket
Shield
Clamp Screw
Clamp Screw
FROM MAINS
Cable
Jacket
Maximum 10 cm from
the Edge of the Drive
TO MOTOR
Cable
Clamp
Shield Clamped
to Bottom of Drive
Jacket
MMC-SD 460 DRIVE
Screw
Shield
Shield Clamped
to Mounting Panel
Clamp
