MMC Smart Drive Hardware Manual - SYSTEM POWER DEVICES
Table 4-1: AC Input Power Requirements
Drive Model
a
a. Drive Model pertains to Analog (no dash suffix) and digital (-D & -DN)
Requirements
Nominal
Input Current
Amps
RMS
1-phase (3-phase)
Transformer
kVA
b
1-phase (3-phase)
b. Transformer sizes shown are worse-case. For a more accurate determination of
transformer size, see section 4.4 on page 51 for calculating application trans-
former requirement.
230 Volt Drives
a
Input
Voltage =
120VAC
Input
Voltage =
230VAC
Input
Voltage =
120VAC
Input
Voltage =
230VAC
MMC-SD-0.5-230 5 (3) 5 (3) .75 (.5) 1.5 (1)
MMC-SD-1.0-230 9 (5) 9 (5) 1.5 (.75) 2 (1.5)
MMC-SD-2.0-230 18 (10) 18 (10) 2.5 (1.5) 4 (2.5)
MMC-SD-3.0-230 18 (14) 18 (14) 2.5 (2) 4 (4)
460 Volt Drives
a
Input
Voltage =
230VAC
Input
Voltage =
460VAC
Input
Voltage =
230VAC
Input
Voltage =
460VAC
MMC-SD-1.3-460 2.8 2.44 1.2 3.0
MMC-SD-2.4-460 4.8 4.18 2.0 5.0
MMC-SD-4.0-460 8.1 7.0 3.4 8.5
MMC-SD-6.0-460 12.4 10.8 5.2 12.8
MMC-SD-8.0-460 17.0 14.8 7.0 17.6
MMC-SD-12.0-460 19.2 16.7 8.0 19.5
MMC-SD-16.0-460 24.2 21.1 10.0 25.0
MMC-SD-24.0-460 38.0 33.1 16.0 39.5
MMC-SD-30.0-460 53.0 46.0 22.0 55.0
MMC-SD-42.0-460 70.0 70.0 29.0 73.0
MMC-SD-51.0-460 84.0 73.0 35.0 87.0
MMC-SD-65.0-460 105 91.0 44.0 110
