MMC Smart Drive Hardware Manual - SYSTEM POWER DEVICES
Figure 4-2: Mounting Dimensions for 230V External Shunt (P/N M.1015.7046)
2.56
65.10
.73
18.60
.52
13.30
1.50
38.10
CLEARANCE HOLES FOR #10
(M5) SCREWS.
NOTE:
1. ALLOW 3.0” (76.2 mm) CLEARANCE IN FRO
N
UNIT FOR CABLES.
2. ALLOW .50” (12.7 mm) ON BOTH SIDES OF
U
3. ALLOW 2.0” (5 cm) ABOVE AND BELOW
.22
5.50
(REF)
7.35
186.70
.25
6.30
.25
[6.30]
NOTE:
1. ALLOW 3.0” (76.2 mm) CLEARANCE
IN FRONT OF UNIT FOR CABLES.
2. ALLOW .50” (12.7 mm) ON BOTH SIDES
OF UNIT.
3. ALLOW 2.0” (5 cm) ABOVE AND BELOW.
