MMC Smart Drive Hardware Manual - SYSTEM POWER DEVICES
Figure 4-3: Mounting Dimensions for 460V External Shunt (P/N M.1302.7048)
Figure 4-4: Mounting Dimensions for 460V External Shunt (P/N M.1302.7049)
Figure 4-5: Mounting Dimensions for 460V External Shunt (P/N M.1302.7060)
2.52 in. (64 mm)
3.66 in. (93 mm)
4.76 in. (121 mm)
20.71 in. (526 mm)
23.82 in. (605 mm)
0 5, 5 x 8
2.52 in. (64 mm)
3.66 in. (93 mm)
4.76 in. (121 mm)
24.65 in. (626 mm)
27.76 in. (705 mm)
0 5, 5 x 8
5.90 in. (150 mm)
7.28 in. (185 mm)
5.12 in. (130 mm)
20.71 in. (526 mm)
23.82 in. (605 mm)
0 5, 5 x 8
