MMC Smart Drive Hardware Manual - SYSTEM POWER DEVICES
Table 4-15: Technical Data for 460V Line Filters
Item
Part Number
M.1302.
5241
M.1302.
5244
M.1302.
5245
M.1302.
5246
M.1302.
5247
M.1302.
5248
M.3000.
0109
Maximum Sup-
ply Voltage
3 x 480VAC, 50/60Hz
Rated current
(at 40°C)
7A 16A 30A 42A 56A 75A 100A
Peak current
1.5 x I
N
for < 1 min. per hour at T
B
= 40°
Test Voltage
Phase/Phase
Phase/Ground
2.1 kVDC for 2 sec. at 25°C
2.7 kVDC for 2 sec. at 25°C
Maximum Con-
nection Cross-
section
4mm
2
4mm
2
10mm
2
10mm
2
4mm
2
25mm
2
50mm
2
Operational
Environmental
Temperature
Range T
B
-25°C ... +55°C
Reduction of rated current from 40°C onwards by 1.4% / °C
Power Loss
(typical)
4W 8W 12W 15W 18W 24W 24W
Site Altitude Below 2000 m above sea level (higher altitudes on request)
Storage Tem-
perature
Range
-25°C ... +85°C
Type of Protec-
tion
IP20
Weight 0.6kg 1.0kg 1.3kg 1.6kg 1.9kg 2.6kg 4.0kg
