MMC Smart Drive Hardware Manual - SYSTEM POWER DEVICES
Table 4-14: Technical Data for 230V Line Filters
M.1015.6922 M.1015.6917 M.1015.6918
Voltage/Freq. 250VAC @ 50/50Hz 250VAC @ 50/50Hz 250VAC @ 50/50Hz
Current 6A @ 50°C 10A @ 50°C 23A @ 50°C
Overload Current
150% 1 minute
200% 1 second
150% 1 minute
200% 1 second
150% 1 minute
200% 1 second
Temperature -25 to 95°C -25 to 95°C -25 to 95°C
Leakage Current 5mA @ 240V, 50 Hz
46mA @ 240V, 50
Hz
200mA @ 250V,
50Hz
Electric Strength 2500VAC/1 minute 2500VAC/1 minute 2500VAC/1 minute
Power Loss 3.5W (Full Load) 2.7W (Full Load) 10W (Full Load)
Terminals
2mm sq. spring
clamp
M4 screw cross/ sq.
2x 2.5mm
M4 screw cross/ sq.
2x 2.5mm
Weight 0.3Kg (0.66 Lb.) 0.95Kg (2.0 Lb) 1.6Kg (2.5 Lb)
Back Mounting
a
a. Line filters are manufactured to millimeter dimensions (inches are approximate con-
versions).
4 x M4 4 x M4 4 x M4
Side Mounting
a
2 x M5 2 x M6 2 x M6
