Kubota MX5100 - Page 100

1-S8
MX5100, WSM
ENGINE
ENGINE BODY (Continued)
W1015276
Item Factory Specification Allowable Limit
Idle Gear Side Clearance 0.12 to 0.48 mm
0.0048 to 0.018 in.
0.9 mm
0.04 in.
Idle Gear Shaft to Idle Gear Bushing
Idle Gear Shaft
Idle Gear Bushing
Oil Clearance
O.D.
I.D.
0.025 to 0.066 mm
0.00099 to 0.0025 in.
37.959 to 37.975 mm
1.4945 to 1.4950 in.
38.000 to 38.025 mm
1.4961 to 1.4970 in.
0.10 mm
0.0039 in.
–
–
Camshaft Side Clearance 0.070 to 0.22 mm
0.0028 to 0.0086 in.
0.30 mm
0.012 in.
Camshaft Alignment – 0.01 mm
0.0004 in.
Cam Height
(Intake)
Height
(Exhaust)
33.90 mm
1.335 in.
33.27 mm
1.310 in.
33.85 mm
1.333 in.
33.22 mm
1.308 in.
Camshaft Journal to Cylinder Block Bore
Camshaft Journal
Cylinder Block Bore
Oil Clearance
O.D.
I.D.
0.050 to 0.091 mm
0.0020 to 0.0035 in.
39.934 to 39.950 mm
1.5722 to 1.5728 in.
40.000 to 40.025 mm
1.5748 to 1.5757 in.
0.15 mm
0.0059 in.
–
–
Balancer Shaft Side Clearance 0.070 to 0.22 mm
0.0028 to 0.0086 in.
0.30 mm
0.012 in.
Balancer Shaft Alignment – 0.02 mm
0.0008 in.
