1-S7
MX5100, WSM
ENGINE
ENGINE BODY (Continued)
W1204063
Item Factory Specification Allowable Limit
Timing Gear
Crank Gear to Idle Gear
Idle Gear to Cam Gear
Idle Gear to Injection Pump Gear
Crank Gear to Oil Pump Gear
Idle Gear to Balancer Gear
Cam Gear to Balancer Gear
Backlash
Backlash
Backlash
Backlash
Backlash
Backlash
0.04150 to 0.1122 mm
0.001634 to 0.004417
in.
0.04150 to 0.1154 mm
0.001634 to 0.004543
in.
0.04150 to 0.1154 mm
0.001634 to 0.004543
in.
0.04150 to 0.1090 mm
0.001634 to 0.004291
in.
0.03500 to 0.1160 mm
0.001378 to 0.004566
in.
0.03500 to 0.1160 mm
0.001378 to 0.004566
in.
0.15 mm
0.0059 in.
0.15 mm
0.0059 in.
0.15 mm
0.0059 in.
0.15 mm
0.0059 in.
0.15 mm
0.0059 in.
0.15 mm
0.0059 in.
