3-S18
MX5100, WSM
TRANSMISSION
Removing 25T Gear Shaft
1. Remove the 25T gear shaft (1) as an assembly from the clutch
housing.
(When reassembling)
• Install the 25T gear shaft not to damage the oil seal (5) installed
in the 25T gear shaft rear end, using a vinyl tape.
W10199890
(1) 25T Gear Shaft
(2) 18T PTO Gear Shaft
(3) 26T Gear
(4) Vinyl Tape
(5) Oil Seal
