9-S29
MX5100, WSM
ELECTRICAL SYSTEM
Bearing on Drive End Side
1. Press out the bearing from drive end frame (3) with a press and
jig (1).
W1137587
Bearing at Slip Ring Side
1. Lightly secure the rotor (1) with a vise to prevent damage, and
remove the bearing (2) with a puller (3).
W1139213
(1) Jig
(2) Block
(3) Drive End Frame
(1) Rotor
(2) Bearing
(3) Puller
