2NM/2NX/2NY/2NZ/2P0/2P6
1-4-24
1020 PF lift motor 1 error
(paper feeder)
After cassette 2 is inserted,
PF lift sensor 1 does not turn
on. This error is detected four
times successively.
Bottom plate ele-
vation mechanism
in the cassette
Check to see if the bottom plate can move
smoothly and repair it if any problem is
found.
Connector cable or
poor contact in the
connector
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
PF lift motor 1 and PF main PWB (YC7)
Drive transmission
system of the PF
lift motor
Check if the gears rotate smoothly. If not,
grease the bushes and gears. Check for
broken gears and replace if any.
PF lift motor Replace the PF lift motor 1.
PF main PWB Replace the PF main PWB (Refer to the ser-
vice manual for the paper feeder).
1030 PF lift motor 2 error
(paper feeder)
After cassette 3 is inserted,
PF lift sensor 2 does not turn
on. This error is detected four
times successively.
Dottom plate ele-
vation mechanism
in the cassette
Check to see if the bottom plate can move
smoothly and repair it if any problem is
found.
Connector cable or
poor contact in the
connector
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
PF lift motor 2 and PF main PWB (YC7)
Drive transmission
system of the PF
lift motor
Check if the gears rotate smoothly. If not,
grease the bushes and gears. Check for
broken gears and replace if any.
PF lift motor Replace the PF lift motor 2.
PF main PWB Replace the PF main PWB (Refer to the ser-
vice manual for the paper feeder).
1040 PF lift motor 3 error
(paper feeder)
After cassette 4 is inserted,
PF lift sensor 3 does not turn
on. This error is detected four
times successively.
Bottom plate ele-
vation mechanism
in the cassette
Check to see if the bottom plate can move
smoothly and repair it if any problem is
found.
Connector cable or
poor contact in the
connector
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
PF lift motor 3 and PF main PWB (YC7)
Drive transmission
system of the PF
lift motor
Check if the gears rotate smoothly. If not,
grease the bushes and gears. Check for
broken gears and replace if any.
PF lift motor Replace the PF lift motor 3.
PF main PWB Replace the PF main PWB (Refer to the ser-
vice manual for the paper feeder).
Code Contents Related parts
Check procedures/
corrective measures
To Next Page
