Kyocera ECOSYS M3040dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
1-4-31
3100 Scanner carriage error
The home position is not cor-
rect when the power is turned
on, at the end of a reading
process of the table and docu-
ment processor.
Image scanner
motor
1. Move the scanner by the hand to check
whether it is unusually difficult to move.
2. Check that the scanner driving belt is not
disengaged.
3. Confirm that the wiring connector is
firmly connected and, if necessary,
connect the connector all the way in.
Image scanner motor and control PWB
(YC1002)
4. If the wiring is disconnected, shorted or
grounded, replace the wiring.
5. Replace the image scanner motor.
Home position
sensor
1. Check that the sensor is correctly
positioned.
2. Confirm that the wiring connector is
firmly connected and, if necessary,
connect the connector all the way in.
Home position sensor and CCD PWB
(YC3)
CCD PWB and control PWB (YC1000)
3. Replace the home position sensor.
CCD PWB
Replace the image scanner unit and
execute U411 (see page 1-3-54).
Control PWB
Replace the control PWB and check for
correct operation (see page 2-2-12).
3200 Exposure lamp error
When a lamp is made to turn
on one side at a time, the
white standard data at the
time of an initial is lower than
a rated value.
LED PWB 1. Reinsert the connector. Also check for
continuity within the connector cable. If
none, replace the cable.
LED PWB and CCD PWB (YC2)
CCD PWB and control PWB (YC1000)
2. Replace the image scanner unit (see
page 1-5-20).
CCD PWB
Replace the image scanner unit and
execute U411 (see page 1-3-54).
Control PWB Replace the control PWB and check for cor-
rect operation (see page 2-2-12).
3500 Communication error
between scanner and ASIC
An error code is detected.
CCD PWB
1. Confirm that the wiring connector is
firmly connected and, if necessary, con-
nect the connector all the way in.
CCD PWB and control PWB (YC1000)
2. If the wiring is disconnected, shorted or
grounded, replace the wiring.
3. Replace the image scanner unit and
execute U411 (see page 1-3-54).
Control PWB Replace the control PWB and check for cor-
rect operation (see page 2-2-12).
Code Contents Related parts
Check procedures/
corrective measures
