2NM/2NX/2NY/2NZ/2P0/2P6
1-4-30
2620 PF drive motor 3 error
(paper feeder 3)
When the PF drive motor is
driven, error signal is detected
continuously for 2 s.
Connector cable or
poor contact in the
connector
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
PF drive motor 3 and PF main PWB (YC6)
Drive transmission
system of the PF
drive motor
Check if the rollers and gears rotate
smoothly. If not, grease the bushes and
gears. Check for broken gears and replace if
any.
PF drive motor Replace the PF drive motor 3.
PF main PWB Replace the PF main PWB (Refer to the ser-
vice manual for the paper feeder).
2630 PF drive motor 4 error
(paper feeder 4)
When the PF drive motor is
driven, error signal is detected
continuously for 2 s.
Connector cable or
poor contact in the
connector
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
PF drive motor 4 and PF main PWB (YC6)
Drive transmission
system of the PF
drive motor
Check if the rollers and gears rotate
smoothly. If not, grease the bushes and
gears. Check for broken gears and replace if
any.
PF drive motor Replace the PF drive motor 4.
PF main PWB Replace the PF main PWB (Refer to the ser-
vice manual for the paper feeder).
Code Contents Related parts
Check procedures/
corrective measures
