2NM/2NX/2NY/2NZ/2P0/2P6
1-4-29
2340 Envelope motor error
(Timeout)
(50/60 ppm model only)
The position detection sensor
is not detected continuously
for 30 s.
Connector cable or
poor contact in the
connector
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Envelope motor and connect left PWB
(YC11)
Connect left PWB and control PWB (YC2)
Drive transmission
system of the
envelope motor
Check if the gears rotate smoothly. If not,
grease the bushes and gears. Check for
broken gears and replace if any.
Envelope motor Replace the envelope motor.
Connect left PWB Replace the connect left PWB (See Page 2-
2-20).
Control PWB Replace the control PWB and check for cor-
rect operation (See Page 2-2-12).
2600 PF drive motor 1 error
(paper feeder 1)
When the PF drive motor is
driven, error signal is detected
continuously for 2 s.
Connector cable or
poor contact in the
connector
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
PF drive motor 1 and PF main PWB (YC6)
Drive transmission
system of the PF
drive motor
Check if the rollers and gears rotate
smoothly. If not, grease the bushes and
gears. Check for broken gears and replace if
any.
DPF drive motor Replace the PF drive motor 1.
DPF main PWB Replace the PF main PWB (Refer to the ser-
vice manual for the paper feeder).
2610 PF drive motor 2 error
(paper feeder 2)
When the PF drive motor is
driven, error signal is detected
continuously for 2 s.
Connector cable or
poor contact in the
connector
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
PF drive motor 2 and PF main PWB (YC6)
Drive transmission
system of the PF
drive motor
Check if the rollers and gears rotate
smoothly. If not, grease the bushes and
gears. Check for broken gears and replace if
any.
PF drive motor Replace the PF drive motor 2.
PF main PWB Replace the PF main PWB (Refer to the ser-
vice manual for the paper feeder).
Code Contents Related parts
Check procedures/
corrective measures
To Next Page
