Kyocera ECOSYS M3040dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
1-5-26
6. Remove four screws.
7. Remove the upper stay assembly
upward.
Figure 1-5-42
8. Remove the screw and then remove the
right inner cover by leaning it inside and
lifting it.
9. Remove two screws and then remove
the left inner cover by leaning it inside
and lifting it.
Figure 1-5-43
Screw
Screw
Screw
Screw
Upper stay
assembly
Right inner
cover
Left inner
cover
Screw
Screw
Screw

Kyocera ECOSYS M3040dn Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Max Paper Size	A4
Scan Resolution	600 x 600 dpi
Output Capacity	250 sheets
Copy Resolution	600 x 600 dpi
Maximum Copy Size	A4
Operating Systems	Windows, Mac OS, Linux
Functions	Print, Copy, Scan
Print Speed	40 ppm
Scan Speed	40 ipm
Connectivity	USB 2.0, Ethernet
Warm-up Time	15 seconds
Memory	512 MB
Paper Size	A4, A5, A6, B5, Letter, Legal
Paper Weight	60-220 g/m²
Copy Speed	40 cpm
Scan Type	Color and Monochrome
