2NM/2NX/2NY/2NZ/2P0/2P6
1-5-47
[40 ppm model]
11. Pull up the release lever of fixing pres-
sure.
12. Remove the screw and then remove the
fuser unit forward.
13. Check or replace the fuser unit and refit
all the removed parts.
Caution: Pull down the release lever of fix-
ing pressure after refitting the fuser
unit.(pressurization state)
Figure 1-5-78
Screw
Fuser unit
Release lever
