Kyocera ECOSYS M3040dn

2NM/2NX/2NY/2NZ/2P0/2P6
2-2-8
YC30
1 AIRTEMP I Analog Temperature sensor input signal
Connected to
the key right
PWB *3
or
the opera-
tion panel
PWB *2
2 AIR WET I Analog Humid sensor input signal
3 GND - - Ground
4 WETCLK O 0/3.3 V DC (pulse) Humid sensor clock signal
YC31
1 GND - - Ground
Connected to
the devel-
oper fan
motor
2 +24V0_E3 O 24 V DC 24 V DC power output
YC1000
1 12V3 E2 O 12 V DC 12 V DC power output
Connected to
the CCD
PWB
2 12V3 E2 O 12 V DC 12 V DC power output
3N.C.
4 +5V3 E3 O 5 V DC 5 V DC power output
5 +5V3 E3 O 5 V DC 5 V DC power output
6 N.C. - - Not used
7 GND - - Ground
8 CCDOSR I Analog Image analog signal RED
9 GND - - Ground
10 CCDOSG(EV
EN)
I Analog Image analog signal GREEN
11 GND - - Ground
12 CCDOSB(OD
D)
I Analog Image analog signal BLUE
13 GND - - Ground
14 CCDSW O 0/3.3 V DC CCD color/BW change signal
15 CCDSH O 0/3.3 V DC Shift gate signal
16 GND - - Ground
17 GND - - Ground
18 CCDPH1+ O LVDS CCD shift register clock signal
19 CCDPH1- O LVDS CCD shift register clock signal
20 GND - - Ground
21 CCDCP- O LVDS CCD clamp signal
22 CCDCP+ O LVDS CCD clamp signal
23 GND - - Ground
24 CCDRS+ O LVDS CCD reset signal
Connector Pin Signal I/O Voltage Description
