Kyocera ECOSYS M3040dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
2-2-9
YC1000
25 CCDRS- O LVDS CCD reset signal
Connected to
the CCD
PWB
26 GND - - Ground
27 N.C. - - Not used
28 +3.3V3 E1 O 3.3 V DC 3.3 V DC power output
29 HP SWN I 0/3.3 V DC HPS: On/Off
30 GND - - Ground
31 M LED C I 0 to 2 V DC LED CATHODE
32 M LED A O 3 V DC LED ANODE
YC1001
1 CONNMOTB2 O 0/24 V DC(pulse) DPCM drive control signal
Connected to
the convey-
ing motor, DP
switchback
motor, DP
paper feed
motor
2 CONNMOTB1 O 0/24 V DC(pulse) DPCM drive control signal
3 CONNMOTA2 O 0/24 V DC(pulse) DPCM drive control signal
4 CONNMOTA1 O 0/24 V DC(pulse) DPCM drive control signal
5 JNCMOTB2 O 0/24 V DC(pulse) DPSBM drive control signal
6 JNCMOTA2 O 0/24 V DC(pulse) DPSBM drive control signal
7 JNCMOTB1 O 0/24 V DC(pulse) DPSBM drive control signal
8 JNCMOTA1 O 0/24 V DC(pulse) DPSBM drive control signal
9 FEEDMOTB2 O 0/24 V DC(pulse) DPPFM drive control signal
10 FEEDMOTB1 O 0/24 V DC(pulse) DPPFM drive control signal
11 FEEDMOTA2 O 0/24 V DC(pulse) DPPFM drive control signal
12 FEEDMOTA1 O 0/24 V DC(pulse) DPPFM drive control signal
YC1002
1 SCMOTB2 O 0/24 V DC(pulse) ISUM drive control signal
Connected to
the image
scanner
motor
2 SCMOTA1 O 0/24 V DC(pulse) ISUM drive control signal
3 SCMOTB1 O 0/24 V DC(pulse) ISUM drive control signal
4 SCMOTA2 O 0/24 V DC(pulse) ISUM drive control signal
YC1003
1 +3.3V3S O 3.3 V DC 3.3 V DC power output
Connected to
the DP origi-
nal sensor,
theDP regist
sensor, DP
open/close
sensor, DP
switchback
sensor, DP
timing sensor
2 GND - - Ground
3 SET_SW I 0/3.3 V DC DPOS: On/Off
4 +3.3V3S O 3.3 V DC 3.3 V DC power output
5 GND - - Ground
6 REGIST_SW I 0/3.3 V DC DPRS: On/Off
7 +3.3V3S O 3.3 V DC 3.3 V DC power output
8 GND - - Ground
9 DP_OPEN_S
W
I 0/3.3 V DC DPOCS: On/Off
10 +3.3V3S O 3.3 V DC 3.3 V DC power output
Connector Pin Signal I/O Voltage Description
