Kyocera ECOSYS M3040dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6-1
2-2-39
14. Open the rear cover.
15. Remove the lower interface cover and
the inlet cover.
Figure 2-2-43
16. Remove two screws.
17. Release the hooks by bending both-
side of the right middle cover and then
remove it by pulling and lifting up for-
ward.
Figure 2-2-44
Rear cover
Hook
Inlet cover
Lower
interface cover
Right middle cover
Screw
Hook
Screw

Kyocera ECOSYS M3040dn Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Max Paper Size	A4
Scan Resolution	600 x 600 dpi
Output Capacity	250 sheets
Copy Resolution	600 x 600 dpi
Maximum Copy Size	A4
Operating Systems	Windows, Mac OS, Linux
Functions	Print, Copy, Scan
Print Speed	40 ppm
Scan Speed	40 ipm
Connectivity	USB 2.0, Ethernet
Warm-up Time	15 seconds
Memory	512 MB
Paper Size	A4, A5, A6, B5, Letter, Legal
Paper Weight	60-220 g/m²
Copy Speed	40 cpm
Scan Type	Color and Monochrome
