Kyocera ECOSYS M3040dn

2NM/2NX/2NY/2NZ/2P0/2P6
2-2-40
18. Pull out the cassette.
19. Remove three screws.
20. Release two hooks by sliding the right
lower cover upward and then remove
the right lower cover.
Figure 2-2-45
21. Release two hooks of the rear left cover
while pulling forward.
22. Remove the rear left cover by rotating.
Figure 2-2-46
Right lower cover
Screw
Screw
Screw
Hooks
Rear left cover
Hooks
