DIGISONDE-4D
SYSTEM MANUAL
VERSION 1.2.11
SECTION 3 - OPERATING INSTRUCTIONS 3-49
Table 3-5. Display Options for Doppler Image
Category
Control
Function
Data Presen-
tation
“Linear scale” checkbox
Represent amplitudes in dB scale or linear scale
“Single range” or “Waterfall” presentation
Presentation as single range (Figure 3-35) or
waterfall (Figure 3-37)
Processing
“Global MPA” checkbox
Use amplitude thresholding, display amplitudes
above threshold in black
“Threshold” text field
Threshold value above MPA
Visual At-
tributes
“Printer color scheme” checkbox
Use black on white background (printer) versus
white on black background (screen) display
“Show title” checkbox
Show standard preface information as title
“Show local time” checkbox
Show additional line in the title with local time
“Local Time types” combobox
Type of LT for displays of local time
“Show interior plot annotation” checkbox
Add Amplitude/Phase labels to the plot back-
ground
“Foreground interior plot annotation” check-
box
Bring plot annotations to the foreground
“Show infoline” checkbox
N/A
“Show logotype” checkbox
Show Digisonde
®
logo in the upper left corner
Crosshair
Line
“Show instant values” checkbox
Add a side window to display values at the
crosshair position
“Show cross-hair Doppler line” checkbox
Add cross-hair line to spectra plots
Browsing
Controls
Browsing and spanning modes
N/A to real-time display
Picture op-
tions
Picture format options
N/A to real-time display
