DIGISONDE-4D
SYSTEM MANUAL
VERSION 1.2.11
5-50 SECTION 5 - SYSTEM SOFTWARE – ANNEX A
Table 5A- 35: Digital Sensors
Bit #
Mnemonic on
schematics
DCART Mnemonic
Description
Go
condition
0
O/X
PWR_PREAMP_V
Preamp power
0
1
-15V
PWR_M15_V
-15 Volt power
0
2
-5V
PWR_M5_V
-5 Volt power
0
3
+3.3V
PWR_P3.3_V
+3.3 Volt power
1
4
+15V
PWR_P15_V
+15 Volt power
1
5
+12V
PWR_P12_V
+12 Volt power
1
6
OverTemp
PWR_OVER_TP
Power card overheating condition
1
7
HW Test Pat
PREP_HW_TESTPAT
Preprocessor HW test pattern
1
8
Tx_Card_Timeouts
TX_CARD_TIMEOUTS
Tx Card Commanding Timeouts since
last BIT program
0
9
+18V
PWR_P18_V
+18 Volt power
1
10
Cmd_Timeouts
CMD_TIMEOUTS
Commanding Timeouts since last BIT
program
0
11
RF_Noise_Low_V
RF_NOISE_LOW_V
Environment RF noise Voltage in Anten-
na with 0 dB gain in antenna switch
measured at the Tracker #4 input
0
12
RF_Noise_High_V
RF_NOISE _HIGH_V
Environment RF noise Voltage in Anten-
na with 9 dB gain in antenna switch
measured at the Tracker #4 input
0
13
Rx_Card_Timeouts
RX_CARD_TIMEOUTS
Rx Card Commanding Timeouts since
last BIT program
0
14
TRACKER1_Card_Timeouts
TRACKER1_CARD_TIMEOUTS
TRACKER1 Card Commanding
Timeouts since last BIT program
0
15
TRACKER2_Card_Timeouts
TRACKER2_CARD_TIMEOUTS
TRACKER2 Card Commanding
Timeouts since last BIT program
0
16
TRACKER3_Card_Timeouts
TRACKER3_CARD_TIMEOUTS
TRACKER3 Card Commanding
Timeouts since last BIT program
0
17
TRACKER4_Card_Timeouts
TRACKER4_CARD_TIMEOUTS
TRACKER4 Card Commanding
Timeouts since last BIT program
0
18
BIT_Card_Timeouts
BIT_CARD_TIMEOUTS
BIT Card Commanding Timeouts since
last BIT program
0
19
20
21
22
23
Table 5A- 36: Analog Static Sensors
Word #
Mnemonic on
schematics
DCART Mnemonic
Description
Range
0
TEMP_SENSE
AMP_TP
Temperature sensor in amplifier chassis
0..1023
1
PDT
PWR_TP
Temperature sensor on power card
0..1023
2
-
-
-
-
3
-
-
-
-
4
RPD
TIM_DATACLK_FR
Up converter Data I&Q Clock frequency
0..1023
5
CP/PE
TIM_PARPORT_FR
Parallel port timing clock
0..1023
6
-
-
-
-
7
-
-
-
-
