WAVERUNNER Xi-A AND MXi-A SERIES
110 WRXi-A-GSM-E Rev A
Acquisition Modes
Singleshot:Fortransientandrepetitivesignals:200ps/divto1000s/div
Sequence:1000segmentsstandard
SequenceTimeStampResolution:1ns
IntersegmentTime:800ns
Acquisition Processing
Time Resolution (minimum, single-shot): 200 ps (5 GS/s); 100 ps
(10 GS/s)
Averaging: Summed averaging to 1 million sweeps; Continuous
averaging to 1 million sweeps
Enhanced Resolution (ERES): from 8.5 to 11 bits vertical resolution
Envelope (Extrema): Envelope, floor, roof for up to 1 million sweeps
Interpolation: Linear, (sinx)/x
Triggering System
Modes:Normal,Auto,Single,andStop
Sources:Anyinputchannel,External,Ext/10,orline;slopeandlevelareunique
toeachsource(exceptline)
CouplingMode:GND,DC50ohms,DC1Mohms,AC1Mohms
PretriggerDelay:0to100%ofmemorysize(ad
justablein1%incrementsor
100ns)
PosttriggerDelay: 10,000divisionsinrealtimemode;limitedatslower
time/divsettings
HoldoffbyTimeorEvents:1nsto20sorfrom1to99,999,999events
InternalTriggerRange:±4.1divfromcenter(typical)
TriggerandInt
erpolatorJitter:</=3ps
rms
(typical)
