GETTING STARTED MANUAL
WRXi-A-GSM-E Rev A 91
7. TouchthePrintNowbutton.
AuxOutput
Inadditiontoacalibrationsignal,thefollowingsignalscanbeoutputthroughthe
AUXOUTPUTconnector:
SquareWave
TriggerOut‐canbeusedtotriggeranother
oscilloscope
DClevel‐areferencelevel
TriggerEnabled canbeusedasagatingfunctionto
triggeranotherinstrumentwhentheoscilloscopeis
ready
Pass/Fail‐allowsyoutosetapulsedurationfrom1
msto500ms.Thispulseoccurswhenpass/failtesting
isactiveandconditionsaremet.
AuxOutputOff‐turnsofftheauxiliaryoutputsignal
Auxiliary Output Setup
1. TouchUtilitiesÆUtilitiesSetup...fromthemenubar.
2. TouchtheAuxOutputtab.
3. Ifyousimplywanta1kHz,1Vsquarewave,touchthebuttonsolabeled.
4. Ifyouwantaspecializedoutput,touchoneofthebuttonsunderUse
AuxiliaryOutputFor.
5. Touchinsideth
eAmplitudefieldandenteravalue,usingthepopup
numerickeypad.IfyouwantaTTLlevelsignal,touchtheTTLLevel
checkbox.TheAmplitudefieldbecomesunavailable.
6. IfyouselectedSquareWave,touchinsidetheFrequencyfieldandentera
value,usingthepop upkeypad.Youca
nsetavaluefrom5.0Hzto5MHz.
7. IfyouselectedPass/Fail,touchinsidethePulseDurationfieldandentera
valuefrom1msto500ms,usingthepopupnumerickeypad.
SettingtheDateandTime
Theinstrumentgivesyouthechoiceofmanuallysettingthetimeanddateor
gettingitfromtheInternet.IfyouelecttogetthetimeanddatefromtheInternet,
youneedtohavetheoscilloscopeconnectedtotheInternetthroughtheLAN
connectorontherearpanel.Youcanalsose
ttimezonesanddaylightsavingstime.
