GETTING STARTED MANUAL
WRXi-A-GSM-E Rev A 113
GridStyles:Single,Dual,Quad,Octal,XY,Single+XY,Dual+XY
WaveformDisplayStyles:Sampledotsjoinedordotsonly
Analog Persistence Display
AnalogandColorgradedPersistence:Variablesaturationl evels;storeseach
trace'spersistencedatainmemory
PersistenceSelections:Selectanalog,color,or3D
TraceSelection:ActivateAnalogPersistenceonalloranycombinationoftraces
PersistenceAgingTime:From500mstoinfinity
SweepsDispla
yed:Allaccumulatedorallaccumulatedwithlasttrace
highlighted
Zoom Expansion Traces
Displayupto4Math/Zoomtraces
Internal Waveform Memory
Waveform:M1,M2,M3,M4(Storefulllengthwaveformswith16bits/datapoint.)
Orsavetoanynumberoffiles(limitedonlybydatastoragemedia).
Setup Storage
FrontPanelandInstrumentStatus:SavetotheinternalharddriveortoaUSB
connectedperipheraldevice.
Interface
RemoteControl:ThroughWindows®AutomationorLeCroyremotecommand
set
GPIBPort(optional):SupportsIEEE488.2
EthernetPort:10/100/1000BaseTEthernetinterface(RJ45connector)
USBPorts:5USBports(oneatfrontofoscilloscope)supportWindows
compatibledevices.
ExternalMonitorPort(standard):15pi
nDTypeSVGAcompatibleDB15;
connectasecondmonitortousedualmonitordisplaymode
ParallelPort:1standard
