WAVERUNNER Xi-A AND MXi-A SERIES
58 WRXi-A-GSM-E Rev A
Ortouchinsidethe
Center,thentheWidth,
fieldsandenteravalue
usingthepopup
numerickeypad.
11. Touchinsidethe
VerticalScalefieldand
selectLinearorLinear
ConstantMaxfromthe
popupmenu:
Alinearhistogram
continuesgrowingas
valuesaccumulate.
Alinearconstant
maximumhistogram
continuallyrescales
itselfandremainswell
withinthegrid.
Viewing Thumbnail Histograms
Histiconsareminiaturehistogramsofparameter
measurementsthatappearbelowthegrid.Thesethumbnail
histogramsletyouseeataglancethestatisticaldistributionof
eachparameter.
1. TouchMeasureÆthenoneoftheMeasureModebuttons:StdVertical,
StdHorizontal,orMyMeasurefromthemenubar.
2. TouchtheHisticonsche
ckboxtodisplaythumbnailhistogramsbelowthe
selectedparameters.
Note:FormeasurementssetupinMyMeasure,youcanquicklydisplayan
enlargedhistogramofathumbnailhistogrambytouchingtheHisticonyouwant
toenlarge.Theenlargedhistogramisshownsuperimposedonthetraceit
describes.ThisdoesnotapplytoStdVerticalorStdHorizontalmeasurements.
Persistence Histogram
Youcancreateahistogramofapersistencedisplayalsobycuttingahorizontalor
verticalslicethroughthewaveform.Youalsodecidethewidthofthesliceandits
horizontalorverticalplacementonthewaveform.
