WAVERUNNER Xi-A AND MXi-A SERIES
112 WRXi-A-GSM-E Rev A
SMART Triggers
Dropout:Triggersiftheinputsignaldropsoutforlongerthanaselectabletime
outbetween1nsand20s.
Glitch:Triggersonpositiveornegativeglitcheswithwidthsselectablefrom500
psto20soronintermittentfaults(subjecttobandwidthlimitofoscilloscope).
SignalorPatte
rnInterval:Triggersonintervalsselectablefrom1nsto20s.
Runt:Triggeronpositiveornegativeruntsdefinedbytwovoltagelimitsand
twotimelimits.Selectbetween1nsand20s.
SlewRate:Activatesatriggerwhentherisingorfallinged
geofapulsecrosses
twothresholdlevels,anupperlevelandalowerlevel.
Automatic Setup
Autosetup:Automaticallysetstimebase,trigger,andsensitivitytodisplaya
widerangeofrepetitivesignals.
VerticalFindScale:Automaticallysetstheverticalsensitivityandoffsetforthe
selectedchannelstodisplayawaveformwithmaximumdynamicrange.
Probes
Probes:Onepassiveprobeperchannelstandard(WR104MXiA,WR104XiA,
WR204XiA);optionalpassiveandactiveprobesareavailable.
ProbeSystem‐ProBus:Automaticallydetectsandsupportsawidevarietyof
compatibleprobes
ScaleFactors:Automaticallyormanuallyselecteddependingonprobeused
Color Waveform Display
Type:Color10.4inchflatpanelTFTLCDwithhighresolutiontouchscreen
Resolution:SVGA;800x600pixels;maximumexternalmonitoroutput
resolutionof2048x1536pixels
RealTimeClock:Date,hours,minutes,andsecondsdisplayedwithwaveform;
accurateto±50ppm;SNTPsupporttosy
nchronizetoprecisioninternetclocks
NumberofTraces:Maximumofeighttraces;simultaneouslydisplayschannel,
zoom,memory,andmathtraces
