GETTING STARTED MANUAL
WRXi-A-GSM-E Rev A 39
TRIGGERING
SimpleTriggers
Edge Trigger on Simple Signals
Theinstrumentusesmanywaveformcapturetechniquesthattriggeronfeatures
andconditionsthatyoudefine.Thesetriggersfallintotwomajorcategories:
StandardTriggers‐activatedbybasicwaveformfeaturesorconditionssuchas
apositiveornegativeslope,andholdoff
SMARTTriggers‐sophisticatedtriggersthatenableyoutousebasicor
complexc
onditionsfortriggering.
UseEdgeTriggersforsimplesignals,andtheSMARTTriggersforsignalswithrare
features,likeglitches.
Controlling Edge Triggering
HORIZONTAL:
TurntheDelayknobintheHORIZONTALcontrolgroupto
adjustthetrigger'shorizontalposition.Or,touchinside
theDelayfieldinthetimebasesetupdialogandentera
value,usingthepopupkeypad.
Thetriggerlocationisshownbyamarkerbelowthegrid
Posttriggerdelayisindicatedbyaleftpointingarrow
belowleftofthegrid.
ThetimevalueisgiveninthetitlelineoftheTimeBase
labelbelowrightofthegrid.
VERTICAL:
TurntheLEVEL knobintheTRIGGERcontrolgroupto
adjusttheverticalthresholdofthetriggerorthe
highlightedtrace.Leveldefinesthesourcevoltageat
whichthetriggergeneratesanevent:achangeinthe
inputsignalthatsatisfiesthetriggerconditions.
