WAVERUNNER Xi-A AND MXi-A SERIES
48 WRXi-A-GSM-E Rev A
TouchtheBrowsebuttonandselectalocationandfilename.
Finally,makesureyoutouchtheSaveSetupbutton.
Note:YoucanloadpreviouslysavedTriggerScansetupsbytouchingtheBrowse
button,locatingthefile,andthenclickingLoadSetup.
WAVEFORMMEASUREMENT S
MeasuringwithCursors
Overview
Cursorsareimportanttoolsthataidyouinmeasuringsignalvalues.Cursorsare
markerslines,crosshairs,orarrowsthatyoucanmovearoundthegridorthe
waveformitself.Usecursorstomakefast,accuratemeasurementsandtoeliminate
guesswork.Therearetwobasictypes:
Horizontal(TimeorFreq
uency)cursorsarelinesthatyoumovehorizontally
alongthewaveform.Placethematadesiredlocationalongthetimeaxisto
readthesignal’samplitudeattheselectedtime.
Vertical(Voltage)cursorsarelinesthatyoumoveverticallyonthegridto
measuretheamplitudeofasignal.
Cursor Measurement Icons
TheShowiconsdepictwhatisbeingmeasuredforeachmeasurementmode.
Absolute
Eachcursorlocatesapointonthewaveform.Thecursor
valuescanbereadinthedescriptorlabelforthetrace.
UsethePositionfieldsattherightsideofthedialogto
placethecursorsprecisely.
Delta
ThisisthedifferenceinYvalues.Thevaluecanberead
inthedescriptorlabelforthetrace.
Abs+Delta
Displaysabsoluteanddeltacursorstogether.
Slope
Thisgivestheslopebetweencursors.
Iftherearenontimedomainwaveformsdisplayed,amenuisshownoffering
choicesofxaxisunits:sorHz,forexample.
